Eaton 170M4412 Magnetic Circuit Breaker

Key Features & Benefits:

• Magnetic-Only Trip: Provides instantaneous short-circuit protection without being affected by surrounding temperature variations.

• 70A Current Rating: Suitable for protecting higher-amperage branch circuits in industrial machinery and power distribution units.

• 1-Pole, 240VAC Rating: Designed for single-phase systems with a voltage rating of 240VAC.

• Industrial-Grade Reliability: Built to Eaton’s stringent quality standards for long service life and consistent performance in harsh conditions.

• Manual ON/OFF Control: Features a robust toggle switch for easy manual operation and clear status indication.

• Compact Footprint: Saves valuable space in control panels and enclosures.

Technical Specifications (Always verify with the official Eaton datasheet):

• Manufacturer: Eaton

• Model: 170M4412

• Series: 170M

• Amperage Rating: 70 A

• Number of Poles: 1

• Voltage Rating: 240 VAC

• Trip Type: Magnetic (Instantaneous)

• Mounting Style: Panel Mount / DIN Rail Mount (Verify specific type)

• Terminal Type: Screw Terminals

• Standards: UL 1077, CSA 22.2 (Verify specific listings)

Typical Applications:

• Industrial Control Panels

• Power Distribution Units (PDUs)

• Machinery and Motor Protection Circuits

• HVAC and Power Generation Equipment

• Disconnect Switch Replacement

• Welding Equipment

• Service Entrance Equipment
