Mitsubishi AA065VB01 6.5″ TFT-LCD Module (640×480 VGA)

📝 Full Product Description

The Mitsubishi AA065VB01 is a 6.5-inch color TFT-LCD module that integrates an LCD panel, driver ICs, control circuitry, and backlight unit. Beyondinfinite.com+1

It supports a 640 × 480 (VGA) resolution with 262K colors (6-bit RGB). Beyondinfinite.com The module is typically powered by 3.3 V or 5.0 V logic for the LCD side. Beyondinfinite.com The backlight is provided by dual CCFL tubes (edge-lit) and requires its own inverter drive. Beyondinfinite.com

Mechanically, the module size is about 154.0 mm × 121.0 mm × 11.0 mm, with an active display area of 132.48 × 99.36 mm. Beyondinfinite.com

Key Features & Benefits

• TFT display with 262K colors, VGA resolution (640 × 480) Beyondinfinite.com

• CMOS / TTL digital interface for display data Beyondinfinite.com

• Good viewing angles (±70° horizontal, ±60° vertical typical) Beyondinfinite.com

• Anti-glare and hard coated front surface (3H) Beyondinfinite.com

• Backlight via dual CCFL lamps, ~50,000 h lifetime typical Beyondinfinite.com

• Compact and relatively thin module form factor

• Suitable for industrial control panels, HMI units, and embedded display applications

Typical Applications

• Industrial human-machine interface (HMI) equipment

• Control panels and operator consoles

• Embedded systems requiring color display

• Test & measurement instrumentation

• Factory automation display modules
