General Specifications
| Item | CJ2H- | |||||
|---|---|---|---|---|---|---|
| CPU64-EIP | CPU65-EIP | CPU66-EIP | CPU67-EIP | CPU68-EIP | ||
| Enclosure | Mounted in a panel | |||||
| Grounding | Less than 100 Ω | |||||
| CPU Rack Dimensions | 90 mm × 65 mm × 80 mm (H × D × W) | |||||
| Weight * | 280 g or less | |||||
| Current Consumption | 5 VDC, 0.82 A | |||||
| Use Envi- ronment |
Ambient Operating Temperature |
0 to 55 °C | ||||
| Ambient Operating Humidity |
10% to 90% (with no condensation) | |||||
| Atmosphere | Must be free from corrosive gases. | |||||
| Ambient Storage Temperature |
– 20 to 70 °C (excluding battery) | |||||
| Altitude | 2,000 m or less | |||||
| Pollution Degree | 2 or less: Meets IEC 61010-2-201. | |||||
| Noise Immunity | 2 kV on power supply line (Conforms to IEC 61000-4-4.) | |||||
| Overvoltage Category | Category II: Meets IEC 61010-2-201. | |||||
| EMC Immunity Level | Zone B | |||||
| Vibration Resistance | Conforms to IEC60068-2-6. 5 to 8.4 Hz with 3.5-mm amplitude, 8.4 to 150 Hz Acceleration of 9.8 m/s2 for 100 min in X, Y, and Z directions (10 sweeps of 10 min each = 100 min total) |
|||||
| Shock Resistance | Conforms to IEC60068-2-27. 147 m/s2, 3 times in X, Y, and Z directions (100 m/s2 for Relay Output Units) |
|||||
| Battery | Life | 5 years at 25 °C | ||||
| Weight | Approx. 10 g | |||||
| Model | CJ1W-BAT01 | |||||
| Applicable Standards | Conforms to cULus, NK, LR and EC Directives. | |||||
