WAGO 236-408 8-Pole PCB Terminal Block

Key Features:

• Proven CAGE CLAMP® Connection: Provides a fast, secure, and maintenance-free termination for solid, stranded, and fine-stranded conductors.
• 8 Poles / Positions: Ideal for multi-wire signal and power distribution on a single component.
• Standard 5mm Pitch: Universal pin spacing for easy PCB layout design.
• Wide Wire Range: Accommodates wire sizes from 14 to 28 AWG (0.08 to 2.5 mm2).
• User-Friendly Design: Horizontal (90°) wire entry and convenient top-entry test ports for easy access and diagnostics.
• High-Quality Construction: Made from durable Polyamide (PA66) with a UL94 V-0 flammability rating for enhanced safety.
• Through-Hole Mounting: Solder pins provide a strong mechanical connection to the PCB.

Technical Specifications:

• Manufacturer: WAGO
• Part Number: 236-408
• Series: 236
• Number of Poles: 8
• Pitch: 5 mm (0.197 in)
• Connection Technology: CAGE CLAMP®
• Actuation Type: Operating Tool
• Mounting Type: Through-Hole, Solder Pin
• Wire Entry Orientation: Horizontal (90° to PCB)
• Wire Gauge (AWG): 14 – 28 AWG
• Nominal Voltage (UL): 300 V
• Nominal Current (UL): 15 A
• Color: Gray
• Housing Material: Polyamide (PA66)
• Flammability Rating: UL94 V-0

Applications:

• Industrial Control Systems
• Power Supplies and Inverters
• Building Automation and HVAC Controls
• Measurement and Test Equipment
• Lighting Technology
• Telecommunication Devices
